Rgb video wall960mm x 960mm Outdoor Advertising Signs with 1 / 4 Scan Constant Current Driving
Product Description:
1. Using DIP technology make the screen have a excellent effect when it plays .
2. The cabinet become more firmed , and corrosion-resistant .
3 synchronization through the screen body color and brightness adjustment, screen body presents a delicate and vivid color performance;
4. high contrast, high refresh rate, making the LE display render the image without any delay, smear phenomenon;
5. compatible with a variety of signal source input, such as AV, S-Video, DVI, VGA, YPbPr, HDMI, SDI, DP, etc.;
6. Flightcase professional packaging protection, of the screen body control equipment has played a good protection;
7. Unique waterproof case designed to meet the IP65 protection standard, and can be directly installed in outdoor use.
Applications:
Mainly for outdoor advertising,information publishing,journalism and communication
in some places,such as cultural square,traffic arteries,stations,terminals,information
centers,entertainment venues,shopping centers,commercial city and etc.
Technical Specification:
| Technical Parameter | P10 Full Color |
| The optimum viewing distance | 10m |
| The optimum viewing angle(Horizontal / Vertical ) | 120 / 90 |
| Maximum power consumption | 900w/m2 |
| Standard cabinet | 960 *960mm |
| Resolution of cabinet | 96 * 96 |
| Weight of cabinet | 50kg / m2 |
| Driving method | 1/4 scan constant current driving |
| Frame frequency | ≥60hz/s |
| Refresh rate | ≥ 200hz |
| Luminance of white balance | ≥6500 CD/m2 |
| Working environment temperature | -30°C~55°C(-30 ~+65 optional) |
| Working voltage | 220±10% or 110±10% |
| Grey scale/color | Displaying colors1.07 billion(synchronized) |
| Brightness adjustment | 256 levels of each color (R,G, B) can be adjusted manually, and 8 levels of each color can be adjusted automatically. |
| Input signal | RF, S-Video, RGB, RGBHV, YUV, YC, Composition, etc. |
| Control system | PCTV non-linear editing card + DVI display card + main controller card + optic fiber transmission(optional) |
| Average no failure time | >5000 hours |
| Life-span | >100000 hours |
| Malfunction dot rate | <0.0001 |
